HP DesignJet T120 at a Glance

Line Drawings                                    70 sec/page, 40 A1 prints per hour

Colour images                                   CQ891A:22.4 m²/hr on coated media;

 2.9 m²/hr on glossy media

Print resolution                                                 Up to 1200 x 1200 optimised dpi from 600 x 600 input dpi

and optimisation for photo paper selected

Margins                                                (top x bottom x left x right) Roll: 5 x 5 x 5 x 5 mm

Sheet: 5 x 17 x 5 x 5 mm

Technology                                         HP Thermal Inkjet

Ink types                                             Dye-based (C, M, Y); pigment-based (K)

Ink colours                                          4 (cyan, magenta, yellow, black)

Ink drop                                              5.5 pl (C, M, Y); 12 pl (K)

Print cartridge volume                   delivered HP 711 Ink Cartridge: black (80 ml); black (38 ml);

cyan, magenta, yellow (29 ml)

Print head nozzles                          1376

Print heads                                         1 (cyan, magenta, yellow, black)

Line accuracy                                     +/- 0.1%

Minimum line width                       0.04 mm (HP-GL/2 addressable)

Guaranteed min line width          0.07 mm (ISO/IEC 13660:2001(E))

Maximum print length                  45.7 m

Maximum print weight                  4.1 kg

Maximum optical density             2.10 maximum black optical density (8 L*min)

Media

Handling                                              Sheet feed; roll feed; input tray; automatic cutter

Types                                                    Bond and coated paper (bond, coated, heavyweight coated, recycled, plain,bright white), technical paper (natural tracing, vellum), film (clear, matte),photographic paper (satin, gloss, semigloss, premium, polypropylene),self-adhesive (adhesive, polypropylene)

Weight                                                                 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray)

Size Input tray                                   : 210 x 279 to 330 x 482 mm; manual feed: 330 x 482 to 610 x 1897

mm; roll: 279 to 610 mm

Thickness                                            Up to 0.3 mm

Memory                                              Standard 256 MB

Hard disk                                             None

Connectivity                                       Interfaces (s tandard) Fast Ethernet (100Base-T); Hi-Speed USB 2.0 certified; WiFi

Print languages                                                 (s tandard) HP PCL 3 GUI, JPEG

Drivers included                               HP PCL 3 GUI driver for Mac OS X and Windows®

Recommended system requirements

Mac                                                       Mac OS X v10.6: Mac computer with Intel® Core™ Processor; 2 GB RAM; 4 GB available hard disk space

Windows                                             Microsoft® Windows® 7: 32-bit (x86) or 64-bit (x64) processor (1 GHz);

2 GB RAM (32-bit) or 4 GB RAM (64-bit); 4 GB available hard disk space; Windows Vista® Ultimate/Business/Home Premium: 32-bit (x86) or 64-bit (x64) processor (1 GHz); 2 GB RAM; 4 GB available hard disk space; Windows® XP Professional/Home (SP3 or higher): Intel® Pentium® family or AMD K6™/Athlon™/Duron™ family (1 GHz); 1 GB RAM; 2 GB available hard disk space
